Key Features
● Flexible Application maintenance,installation mounted etc.,Easy methods installation and pole-mounted,wall-
● High Reliability IP55 suitable indoor or outdoor power supply for telecom base station
● Intelligent Reducing power costs Energy slicing for on- demand Battery backup,support APP/RS485 monitoring
Application Scenarios
● BBU/RRU site
● New-built wireless site
● Indoor or outdoor wireless coverage sites/transmission node sites
● Legacy power transformation to reuse cabinet or rack
● Enterprise telecom scenario
Specification
Rated power | 12000W |
Model | HTP48200 |
Input voltage range | 220/380VAC |
Frequency range | 45Hz~65Hz |
Efficiency | 96% |
Output voltage | 53.5 VDC(42—58 VDC) |
Output power distribution | 9x16A/1P or 3x63A 6x32A |
Grid Environment | 1st/2nd/3rd rate grid* |
Battery distribution | 2x63A |
Battery holder | 48V/100AH(Optional) |
AC SPD | C class |
Lightning protection | In=10kA/IMax=20KA,8/20μ |
Operating temperature | -40℃~+55℃ |
Communication interface | RS485/Dry contact /4G |
Dimension(HxW×D) | 700mm×580mm×350mm |
Weight | ≤45kg |
lprating | IP55 |
