Key Features
●Flexible Application
Easy installation and maintenance,1-hour deployment, installation through various methods such as pole-mounted,wall-mounted etc.
● High Reliability
IP65 suitable indoor or outdoor power supply for telecom base station
● Intelligent
Reducing power costs Energy slicing for ondemand Battery backup,support APP/RS485 monitoring
Application Scenarios
●RRU/AAU remote site
●Outdoor Easy Macro Site
●Enterprise telecom scenario
Specification
Rated power | 3000W |
Model | DPU60 |
Input voltage range | 160-280VAC |
Frequency range | 45Hz~65Hz |
Efficiency | 95% |
Output voltage | 53.5 VDC(42—58 VDC) |
Output power distribution | 3×40A |
Battery distribution | 1×40A(Optional) |
Lightning protection | In=10kA/IMax=20KA,8/20μ |
Operating temperature | -40℃~+55℃ |
Communication interface | RS485/Bluetooth/4G(Optional) |
Dimension(HxWxD) | 398mm×275mm×73mm |
Weight | ≤8kg |
IP rating | IP65 |
Cooling method | Natural heat dissipation |
Installation | Wall-mounted,pole-mounted, |
