Key Features
●Flexible Application
Easy installation and maintenance,
widely applied in any rack or cabinet front maintenance
● Intelligent
Small size,only 1U in height,high power density, support detection of total input current,support network monitoring
● Customized system
DC power distribution support ODM by cutomer need
Application Scenarios
●BBU/RRU site power DC distribution expansion.
●Legacy power transformation to reuse cabinet or rack
● Enterprise telecom scenario
Specification
Rated power | 200A/300A |
Model | DCDU48200 |
Input voltage range | 40-60VDC |
Frequency range | 45Hz~65Hz |
Output voltage | 53.5 VDC(42—58 VDC) |
Output power distribution | Secondary load:6×63A,4× 32A Important load:2×32A,2× 20A,2×16A |
Battery distribution | 1×125A |
Lightning protection | 10/20kA(8/20μs) |
Operating temperature | -40℃~+65℃ |
Communication interface | RS485/Bluetooth/4G |
Dimension(HxW×D) | 44mm×482mm×255mm |
Weight | ≤10kg |
IP rating | IP20 |
Cable routing | Front-in,Front out |
Cooling method | Natural heat dissipation |
