Key Features
●Flexible Application
Standard &compact structure,widely applied in any rack or cabinet
●Intelligent
LCD display ,Refined management improves reliability; Monitoring Humiditure/smoke/access control/water immersion.lithium batteries facilitate capacity expansion
● Customized system
capacity 60-1000A be customized,and AC power distribution/DC power distribution support ODM
Application Scenarios
● BBU/RRU site
● New-built wireless site
● Indoor or outdoor wireless coverage sites /transmission node sites
● Leaacv power transformation to reuse cabinet or rack
Specification
Model | ETP300 |
Input voltage range | 85-300VAC |
Frequency range | 45Hz~65Hz |
Efficiency | 96% |
Output voltage | 53.5 VDC(42—58 VDC) |
Output power distribution | 6×63A(Optional Configuration) 6×32A(Optional Configuration) |
Battery distribution | 2x125A |
Lightning protection | In=20 kA/IMax=40KA,8/20μ |
Operating temperature | -40℃~+75℃ |
Communication interface | RS485/SNMP V3/4G |
Dimension(HxW×D) | 221mm×482mm×360mm |
Weight | ≤20kg |
IP rating | IP20 |
Cooling method | Fan |
