Key Features
● Flexible Application
Standard & compact structure, widely applied in any rack or cabinet
●Intelligent
LCD display,Refined management improves reliabilty; Monitoring Humiditure/smoke/access control/water immersion.lithium batteries faciltate ca acit ex ansion
● Customized system
capacity 60-1000A be customized, and AC power distribution/DC power distribution support ODM
Application Scenarios
● BBU/RRU site
● New-built wireless site
●Indoor or outdoor wireless coverage sites transmission node sites
● Leaacv power transformation to reuse cabinet or rack
Specification：
Rated power | 400A/24KW |
Model | ETP400 |
Input voltage range | 220/380VAC |
Frequency range | 45Hz~65Hz |
Efficiency | 96% |
Output voltage | 53.5 VDC (42—58 VDC) |
Output power distribution | LLVD-6×63A(Optional) BLVD-3x125A 6×32A(OPS) |
Battery distribution | 4x125A |
Lightning protection | In=20 kA/IMax=40KA,8/20μ |
Operating temperature | -40℃~+75℃ |
Communication interface | RS485/SNMP V3/4G |
Dimension(HxWxD) | 221mm×482mm×360mm |
Weight | ≤30kg |
IP rating | IP20 |
Cooling method | Fan |
