Key Features
●Flexible Application
Easy installation and maintenance,1-hour deployment,nstalilation methods pole-mounted,wall-mounted etc.,Output termina is A Quick plug terminals with replaceable fuse
●High Reliability
IP65 suitable indoor or outdoor power supply for telecom base station
● Intelligent
Reducing power costs Energy slicing for ondemand Battery backup,support APP/RS485 monitoring
Application Scenarios
●RRU/AAU remote site
●Outdoor Easy Macro Site
●Enterprise telecom scenario
Specification
Rated power | 6000W |
Model | DBU120 |
Input voltage range | 90-300VAC |
Frequency range | 45Hz~65Hz |
Efficiency | 96% |
Output voltage | 53.5 VDC(42—58 VDC) |
Output power distribution | 7×40A |
Battery distribution | 2x125A |
Lightning protection | In=10kA/IMax=20KA,8/20μ |
Operating temperature | -40℃~+55℃ |
Communication interface | South(DB9):2×CAN North(DB15):1×RS485*(4 line)/Bluetooth/4G |
Dimension(HxWxD) | 400mm×300mm×90mm |
Weight | ≤15kg |
IP rating | IP65 |
Coolingmethod | Naturalheatdissipation |
