Key Features
1.Flexible Application:Standard & compact structure, widelyapplied in any rack or cabinet
2.Intelligent:LCD display ,Refined management improvesreliability;MonitoringHumiditure/smoke/access control/waterimmersion.lithium batteries facilitate capacityexpansion
3.Customized:systemcapacity 60-1000A be customized, andAC power distribution/DC power distribution support ODM
Application Scenarios
1.BBU/RRU site
2.New-built wireless site
3.Indoor or outdoor wireless coverage sites /transmission node sites
4.Leaacv power transformation to reuse cabinet or rack
Model | ETP200 |
Input voltage range | 85-300VAC |
Frequency range | 45Hz~65Hz |
Efficiency | 96% |
Output voltage | 53.5 VDC(42—58 VDC) |
Output power distribution | 6×63A (Optional Configuration) 6×32A(Optional Configuration) |
Battery distribution | 1×125A |
Lightning protection | In=20 kA/IMax=40KA,8/20μ |
Operating temperature | -40℃~+75℃ |
Communication interface | RS485/SNMP V3/4G |
Dimension(HxWxD) | 88mm×482mm×360mm |
Weight | ≤13kg |
IP rating | IP20 |
Cooling method | Fan |
