Key Features
●Cycle life is up to 1000 times @100%DOD,35℃ High charge acceptance to ensure rapid and complete recharge
● Wide working temperature -40℃~+55℃
● High protection level:IP65,Support Parallel
Application Scenarios
●RRU/AAU remote site
●Outdoor Easy Macro Site
●Enterprise telecom scenario
Specification
Model | DBU50 |
Nominal Voltage | 48VDC |
Operating Voltage | 47V DC～57V DC |
Efficiency | 96% |
Output voltage | 48 VDC(42—58 VDC) |
Charging /Discharging Current | Charge:10 A Discharge:maximum 50 A |
Battery distribution | 2x60A Quick plug terminals |
Protection | Over temperature,over current, short circuit,over charge/discharge,etc. |
Operating temperature | -40℃~+55℃ |
Communication interface | DB9:CAN |
Dimension(HxWxD) | 360mm×345mm×150mm |
Weight | ≤26kg |
IP rating | IP65 |
