Key Features
●Flexible Application
Easy installation and maintenance,1-hour deployment, installation through various methods such as pole-mounted, wall-mounted etc.
● High Reliability
IP65 suitable indoor or outdoor power supply for telecom base station
● Intelligent
Reducing power costs Energy slicing for ondemand Battery backup,support APP/RS485 monitoring
Application Scenarios
●RRU/AAU remote site
● Outdoor Easy Macro Site
● Enterprise telecom scenario
Specification
Rated power | 1500W |
Model | DPU30 |
Input voltage range | 160-280VAC |
Frequency range | 45Hz~65Hz |
Efficiency | 95% |
Output voltage | 53.5 VDC(42—58 VDC) |
Output power distribution | 3×30A |
Battery distribution | N/A |
Lightning protection | In=10kA/IMax=20KA,8/20μ |
Operating temperature | -40℃~+55℃ |
Communication interface | RS485/Bluetooth/4G(Optional) |
Dimension(HxW×D) | 278mm×185mm×90mm |
Weight | ≤5kg |
IP rating | IP65 |
Cooling method | Natural heat dissipation |
Installation | Wall-mounted,pole-mounted, |
