Key Features
●Flexible Application Easy installation and maintenance,1 hour deployment,installation methods pole-mounted,wall- mounted etc.,High Reliability IP65 suitable indoor or outdoor power supply for telecom base station
●Intelligent Reducing power costs Energy slicing for on- demand Battery backup,support APP/RS485 monitoring
Application Scenarios
● New-built wireless site unstable grid power
● Grid hybrid solution removes gensets
● Diesel hybrid solution reduces fuel consumption in suburban areas
● Solar hybrid solution eliminates genets and minimizes maintenance in remote areas
● Power supply for macro station and outdoor cabinet
Specification
Rated power | 3000W |
Model | DPS60 |
PV Input voltage range | 100-400VDC |
Frequency range | 45Hz~65Hz |
Efficiency | 96% |
Output voltage | 54.5 VDC(42—58 VDC) |
Output power distribution | 3×40A |
Battery distribution | 1x60A |
Lightning protection | In=10kA/IMax=20KA,8/20μ |
Operating temperature | -40℃~+55℃ |
Communication interface | South(DB9):2×CAN North(DB15):1×RS485*(4 line)/Bluetooth/4G |
Dimension(HxWxD) | 362mmx325mm×60mm |
Weight | ≤8kg |
IP rating | IP65 |
Cooling method | Natural heat dissipation |
Installation | Wall-mounted,pole-mounted, |
